KCI 등재
초분광 이미지를 이용한 배나무 화상병에 대한 최적 분광 밴드 선정
Spectral Band Selection for Detecting Fire Blight Disease in Pear Trees by Narrowband Hyperspectral Imagery
강예성 ( Ye-seong Kang ) , 박준우 ( Jun-woo Park ) , 장시형 ( Chan-seok Ryu ) , 송혜영 ( Si-hyeong Jang ) , 강경석 ( Hye-young Song ) , 유찬석 ( Kyung-suk Kang ) , 김성헌 ( Seong-heon Kim ) , 전새롬 ( Sae-rom Jun ) , 강태환 ( Tae-hwan Kang ) , 김국환 ( Gul-hwan Kim )
UCI I410-ECN-0102-2022-500-000583338

In this study, the possibility of discriminating Fire blight (FB) infection tested using the hyperspectral imagery. The reflectance of healthy and infected leaves and branches was acquired with 5 nm of full width at high maximum (FWHM) and then it was standardized to 10 nm, 25 nm, 50 nm, and 80 nm of FWHM. The standardized samples were divided into training and test sets at ratios of 7:3, 5:5 and 3:7 to find the optimal bands of FWHM by the decision tree analysis. Classification accuracy was evaluated using overall accuracy (OA) and kappa coefficient (KC). The hyperspectral reflectance of infected leaves and branches was significantly lower than those of healthy green, red-edge (RE) and near infrared (NIR) regions. The bands selected for the first node were generally 750 and 800 nm; these were used to identify the infection of leaves and branches, respectively. The accuracy of the classifier was higher in the 7:3 ratio. Four bands with 50 nm of FWHM (450, 650, 750, and 950 nm) might be reasonable because the difference in the recalculated accuracy between 8 bands with 10 nm of FWHM (440, 580, 640, 660, 680, 710, 730, and 740 nm) and 4 bands was only 1.8% for OA and 4.1% for KC, respectively. Finally, adding two bands (550 nm and 800 nm with 25 nm of FWHM) in four bands with 50 nm of FWHM have been proposed to improve the usability of multispectral image sensors with performing various roles in agriculture as well as detecting FB with other combinations of spectral bands.

Ⅰ. Introduction
Ⅱ. Material and Methods
Ⅲ. Results and Discussion
Ⅳ. Conclusions
적 요
REFERENCES
