KCI 등재
전도성 카본 잉크를 이용한 직류 저항형 습도센서 제작 및 평가
Evaluation of DC Resistive Humidity Sensors Based on Conductive Carbon Ink
안태창 ( Taechang An )
센서학회지 26권 6호 397-401(5pages)
UCI I410-ECN-0102-2018-500-003792183
* 발행 기관의 요청으로 이용이 불가한 자료입니다.

A DC resistance type humidity sensor using conductive carbon ink was fabricated and its performance was evaluated. The humidity sensor was fabricated using a screen printing technique and have a structure that does not require additional metal electrodes to measure resistance change. To evaluate the performance of the humidity sensor, we measured the DC resistance change under various relative humidity levels. The fabricated humidity sensor showed a resistance change of about 2.5 ~ 50 kΩ in 11 ~ 95% RH environment. It also shows a linear relationship in the relative humidity versus log DC resistance graph. In comparison with commercial humidity sensor under real environment, it can be confirmed that the resistance of the humidity sensor changes to almost the same level as the measured humidity. These results show that the resistance type humidity sensor can be operated stably in actual environment.
